BORMA 5 TONS 5000BORHP
- Borma room have ingredient Steel frame and Panel wall
- Steel frame made by box steel 50mm*100mm, 1.8mm thickness
- Panel wall made by insulation panel, 50 mm thickness, specifict weight 12kgs/m3
- Inside borma, that we have 20 trolleys, each trolley content 40 trays, each tray content 6-7 kgs fresh kernel, capacity 4800 kgs -5600 kgs each heating time
- Time of heating : 22 to 24 hours ( belong to each fresh kernel)
- Automatic electric power off when temperature reach maximum limit
- Price including 20 trolleys inside borma ( 40 trays/ trolley)
- HS code : 85143990
Description
- FOB HochiMinh
- Cargo code: 5000BORHP
- Size (L*W*H) 9.0m*2.8m*2.8m
- Electric consumption: 6.5kw /3pha / 380V
| No | Ingredient | Qnt | Information |
| 1 | Heat resistant fan | 6 | Capacity 1.5 HP, made in Vietnam |
| 2 | Radiator | 2 | Made by Steel Pipe, diameter 34mm, 4.5m length, 2.0mm thickness Thin steel sheet of 60mm, 0.5mm thickness scrolled around steel pipe Made in Vietnam |
| 3 | Input temperature pipe | 1 | Made by steel pipe, diameter 34mm, 2mm thickness |
| 4 | Output water pipe | 1 | Made by steel pipe, diameter 34mm, 2mm thickness combine Stain steel Valve 34, automatic drainage. Valve made in Korea |
| 5 | Electric cabinet and Alarm | 1 | Electric control center, made in Vietnam |
Cargo description :
- Borma room have ingredient Steel frame and Panel wall
- Steel frame made by box steel 50mm*100mm, 1.8mm thickness
- Panel wall made by insulation panel, 50 mm thickness, specifict weight 12kgs/m3
- Inside borma, that we have 20 trolleys, each trolley content 40 trays, each tray content 6-7 kgs fresh kernel, capacity 4800 kgs -5600 kgs each heating time
- Time of heating : 22 to 24 hours ( belong to each fresh kernel)
- Automatic electric power off when temperature reach maximum limit
- Price including 20 trolleys inside borma ( 40 trays/ trolley)
- HS code : 85143990
Technical guarantee : 1 year
